Mimosa C6x Lite Edition (LE)

Product Overview

The Mimosa C6x Lite Edition is a cost-focused 6 Series fixed wireless radio designed for scalable broadband deployments. It delivers up to 1.0 Gbps in PTP mode and up to 750 Mbps in PTMP mode, with streamlined 80 MHz channel operation and support for the N5-X modular antenna family.

Key Specifications

• PTP Aggregate Speed: Up to 1.0 Gbps
• PTMP Aggregate Speed: Up to 750 Mbps
• Frequency: 5.15–7.125 GHz*
• Antenna Gain Options: 8–30 dBi
• Dimensions: 175 mm H x 70 mm W x 61 mm D
• Weight: 0.7 kg (1.54 lbs)
• Power Consumption: 20 W Max
• Max Output Power: 27 dBm
• IP Rating: IP67
• Channel Operation: Streamlined 80 MHz operation
• Built-in Antenna: 8 dBi

*Frequency operation is subject to hardware/chipset support and country of operation.

Deployment

Designed for broadband service providers, MDU, video security, enterprise and campus networks, and public safety deployments. The Lite Edition uses the same hardware platform as the C6x, with software-defined differences and reduced throughput.
