Ubiquiti airMAX M5 bridge with a 400 mm reflector and 25 dBi antenna for fixed 5 GHz links.
Applications
Use for compatible network deployments after confirming power, frequency and regional requirements.
Official technical specifications
Technical specifications
Mechanical
| Dimensions | 420 x 420 x 275 mm |
|---|---|
| Weight | 1.8 kg |
| Enclosure | UV-stabilized polycarbonate |
| Mounting | Pole mount included |
| Wind survivability | 200 km/h |
Hardware
| Networking interface | 1 x GbE RJ45 |
|---|---|
| Power method | Passive PoE, pins 4/5 (+) and 7/8 return |
| Power supply | 24V, 0.5A Gigabit PoE adapter included |
| Voltage range | 20–27V DC |
| Maximum consumption | 8W |
Wireless
| Antenna gain | 25 dBi |
|---|---|
| Maximum TX power | 26 dBm |
| Frequency range | 5170–5875 MHz worldwide; regional restrictions apply |
